Support Unit For Ball screw

Support unit for ball screw helps to support each shaft-ends of

ball screw. We, S.I.M provides diverse options according to sizes,

loads and purposes for our customers’ best convenience.

Support Unit for Ball Screw (Index)

Installation Guide Made-To-Order

Motor Bracket Unit

Product Overview
  • C-SBU-2D (.dwg)
  • C-SBU-3D (.step)
C-SBU Series
C-SBU(FIXED-SIDE / CLEAN TYPE)

Locknut InstallationGuide Videoyoutube icon

Locknut Installation Guide Video QR Code

Dimensions
Model CAD Sizes (mm)
d1 D W H L h b W1 W2 M PCD N B C1 C2
C-SBU-8.38.3 8 30 64 41 76 21 32 40 35 M3 DP8 45 6.5 14 7.5 5.5
C-SBU-8.40.4 8 30 64 41 76 21 32 40 35 M4 DP10 46 6.5 14 7.5 5.5
C-SBU-10.38.3 10 30 70 46 84 25 35 42 42 M3 DP8 45 8 16 5.5 5.5
C-SBU-10.40.4 10 30 70 46 84 25 35 42 42 M4 DP10 46 8 16 5.5 5.5
C-SBU-12.38.3 12 30 72 47 84 25 36 44 44 M3 DP8 45 8 16 5.5 5.5
C-SBU-12.40.4 12 30 72 47 84 25 36 44 44 M4 DP10 46 8 16 5.5 5.5
C-SBU-12.60.5 12 50 98 61 94 31 49 62 44 M5 DP15 70 8 16 5.5 5.5
C-SBU-15.60.5 15 50 98 61 112 31 49 62 52 M5 DP13 70 8 18 10 10
C-SBU-15.80.6 15 70 128 82 121 41 64 82 52 M6 DP15 90 8 18 10 10
C-SBU-20.60.5 20 50 116 70 139 35 58 70 68 M5 DP13 70 11 28 11 11
C-SBU-20.80.6 20 70 128 82 149 41 64 82 68 M6 DP15 90 11 28 11 11
Model CAD Sizes (mm)
d2 P1 P2 T1 T2 H1 L1 L2 I1 I2 S1 S2
C-SBU-8.38.3 5.5 10 6 47 52 19 67 9 41 30 12 14
C-SBU-8.40.4 5.5 10 6 47 52 19 67 9 41 30 12 14
C-SBU-10.38.3 6.5 10 7 54 56 23 74 10 49 34 10 15
C-SBU-10.40.4 6.5 10 7 54 56 23 74 10 49 34 10 15
C-SBU-12.38.3 6.5 10 7 54 58 23 74 10 49 34 11 14
C-SBU-12.40.4 6.5 10 7 54 58 23 74 10 49 34 11 14
C-SBU-12.60.5 8.5 13 9 58 80 26 84 10 56 52 13 15
C-SBU-15.60.5 8.5 13 9 71 80 26 97 15 63.5 52 16 17.5
C-SBU-15.80.6 8.5 16 11 74 106 36 106 15 69 72 17 20
C-SBU-20.60.5 10.5 20 11 77 94 30 117 22 68 60 19 30
C-SBU-20.80.6 10.5 20 11 87 106 36 127 22 73 72 24 30

※ Please use the jig included in the product package when assembling lock nuts for flange sizes 38mm and 40mm. For more detailed information, please refer to the instruction video or contact our customer service team.
